Functions
Applications
Specifications
| Performance Index | |
| Operating Frequency |
902 - 928MHz, 865 - 868MHz, RF band customized (optional)
|
|
Frequency Hopping |
HSS or Fixed Frequency |
|
Power Output |
+20dBm ~ +30dBm@50Ω load, 1dBm each step |
|
Antenna Interface |
4 channel SMA |
|
Communication Interfaces |
RS-232 / USB2.0 / Ethernet |
|
Optional Interfaces |
RS-485, Wiegand26/34, PoE |
|
Optional Wireless Module |
802.11 WIFI |
|
I/O Interfaces |
2-channel Relay Output, 2-channel 12V level signal output, 2-channel photoelectric isolation input |
|
Firmware Upgrade |
Ethernet |
|
Application Software Platform |
API(C++, C#) development kit (can be customized)
|
|
Tag Operation |
|
| Tag Protocol |
EPC Class 1 Gen 2(ISO18000-6C) |
|
Reading Range |
0~15m(depends on antenna) |
|
Writing Range |
0~5m |
|
Mechanical/Electric Performance |
|
| IP Rating |
IP54 |
|
Indicator |
Buzzer and LED (Power, Antenna, Reading/Writing) |
|
Power |
DC 12V input, PoE optional |
|
Power Consumption |
2W(Standby), 10W(Working) |
|
Product Dimension |
250mm×164mm×46mm |
|
Package Dimension |
320mm×226mm×133mm |
|
Net Weight |
1.48kg |
|
Gross Weight |
2.2kg |
|
Operating Temperature |
-40℃ ~ +60℃ |
|
Storage Temperature |
-60℃ ~ +80℃ |
|
Humidity |
5% ~ 95%(non-condensing) |
Our Services
Wondering if our RFID device can work for you? Finding out is simple.
We are accepting your sample materials to run through our RSTC Lab for free testing and get the result. (You just need provide test sample)
We supply customers with better product, quicker response, more value added expertise service.
We provide personalized customization services, such as logo, software and hardware customization etc.
