UHF frequency band, equipped with 12dBi linear antenna
Support standard RS-232, 10M/100M Ethernet interfaces
Multi groups of I/O interfaces optional, through which controlling the functional mode of the reader/writer
Strong API user interface
Rugged Rugged All In One design with IP67 protecting rate, high durability in tough environment
Applications
Parameters
| UHF | |
| RF Protocol | EPC Global UHF Class 1 Gen2 / ISO18000-6C |
| Engine | Based on Impinj E710 |
| Frequency | 902~928MHz, 865~868MHz |
| Operation Mode | FHSS / Fixed frequency |
| Antenna Gain | Built-in 12dBi linear polarization antenna |
| Power Output | +20dBm ~ +30dBm@50Ω load, 1dBm each step |
| Communication Port | RS-232, 10M/100M Ethernet interfaces |
| Power |
External power adapter (150 ~ 240V / 50Hz AC input and DC outputting 12V / 3A) |
| Power Assumption | 2W(Standby), 10W(Working) |
| IO Port |
Two group relay output or two group level detection input is optional |
| Reading Range | 0~12m (depends on antenna and tag type) |
| Writing Range | 0~5m (depends on antenna and tag type) |
| Supported Regions |
China, Korea, Malaysia, Japan US, Canada and other regions following U.S. FCC Europe and other regions following ETSI EN 302 208 |
| Mechanical & Electrical Performance | |
| Dimension | 400×400×85mm |
| Weight | 3.5kg |
| Material | ABS Industrial casing |
|
Work Temperature |
-40℃～+75℃ |
| Storage Temperature | -40℃～+80℃ |
| IP Rate | IP67 |
