Functions
Support RS-232, Wiegand 26/34 &10/100M Ethernet and customized interfaces
waterproofing IP67, harsh environment suitable
All the design, components model and production process meet relevant military standards,
Multi-reader operating under intensive environment
Command-trigger, set time-trigger and out-trigger suitable for customer’s applications
Multi-group I/O ports, to control the functional mode of the reader/writer
Power supply(AC 110-280V; DC 9V-18V) configurable by requirement
Wireless module GPRS/GSM, WIFI optional
Reading distance is adjustable by software
Parameters
| RF Parameters | |
| Operating Frequency |
2.4-2.48GHz
|
| Output Power | Max +15dBm,step -2dB, software adjustable-30dBm-0dBm (adjustable by software) |
| Sensitivity | -93dBm |
| Communication Interface | RS-232, 10 / 100M Ethernet |
| Optional Interfaces |
RS-485, Wiegand 26/34 |
| Wireless Expansion Module |
GPRS (optional), 802.11 WIFI module(optional) |
| I/O Port |
2- channel relays output(optional), 2- channel trigger input(optional) |
| Firmware Upgrade |
Support serial port |
| Application Software Platform |
Provide development kit of API(C++ and C#) |
| Tag Operation | |
| Tag Protocol | Private protocol |
| Tag Operating Mode |
Compatible with active and passive operating mode tags |
| Reading Range | 0-120m (depend on the tag power output) |
| Identification Speed |
300pcs/s (tag ID) |
| Anti-confliction | Identifying 300pcs tag at the same time |
| Mechanical and Electrical Properties | |
| Indicator | Buzzer, LED (Power, Reading, Data transmission) |
|
Product Dimensions |
Φ330mm×126mm (excluding stand); Φ13.0 in×5.0 in (excluding stand) |
| Package Dimensions |
560mm×380mm×185mm
|
| Power Loading | 300mW |
| Net Weight | 1.6kg |
| Gross Weight |
5.15kg |
| Power Supply | AC180V~240V (optional DC 9-18V power module build-in) |
| Power Consumption |
300mW |
| Operating Temperature | -40℃~+60℃ |
| Storage Temperature | -60℃~+80℃ |
| Humidity | 5% ~ 95% (non-condensing) |
| IP Rating | IP67 |
| Shock Resistance | 10~500Hz, 100mm/15g, triaxial |
