Functions
Parameters
| RF Parameters | |
| Operating Frequency |
2.4-2.48GHz
|
| Power Output | Max +15dBm,step -2dB, software adjustable |
| Receive Sensitivity | -93dBm |
|
Antenna |
Build-in 15dBi vertical polarized antenna |
| I/O Port | 2-channel relays output(Optional), 2--channel tigger inputt(Optional) |
| Firmware Upgrade | Support RS 232 connection updating with specified software |
| Antenna Parameter | API in C++/C#Half power angle: Hor:45-Ver:45; Antenna front to back ratio ≥18dB |
| Communication Interface | |
| Communication Interface | RS-232 interface, 10 / 100M adaptive Ethernet |
| Interface (Optional) |
RS-485 interface, Wiegand 26/34 interface |
| Gpio (Optional) | 2 channel trigger(optical isolated) input (5V,<20mA); 2 channel relay output (30V,<1000mA) |
| Tag Operation | |
| Tag Protocol | Private protocol |
| Tag Working Mode |
Support active and passive active tags |
| Tag Reading Distance | 8~260 meters (outdoor line of sight distance test, actual reading distance depends on antenna type, environment, tag type) |
| Number of Identification Tags |
300 pcs/s (Ethernet connection test) |
| Anti-confliction | indentifiying 300pcs tag at the same time |
| Mechanical and Electrical Properties | |
| Dimension | 320mm × 200mm × 75mm |
|
Weight |
1.8kg |
| Power Consumption |
Standby 200mw, working 400mW
|
| Power Loading | 300mW |
| Working Temperature | -40°C~+60°C |
|
Storage Temperature |
-60°C~+80°C |
| Operating Humidity | 5% ~ 95% (non-condensing) |
| Indicator |
Buzzer |
| Vibration | 10~500Hz，100mm/15g, three axis |
| IP Rating | IP67 |
